Modal model for the new SRC

Starting from the input beam model described in alog 30126, I expanded the modal model to include the new arm cavities and new SRC.

The optics location data is based on:
- https://galaxy.ligo.caltech.edu/optics/ for optics ROC and glass thicknesses
- E1400205 for BS, ITMX, ITMY, SR3, SR2 and SRM locations (SR2 location moved by 5cm towards the BS compared to E1400205)

While the code is a bit lengthy, it only builds simple structures describing sections of the interferometer:

SRCrt =

    lambda: 1.0640e-06
         q: -1.8528e+03 + 4.0141e+02i
         N: 8
      dist: [0 0 24.4907 15.4657 15.7441 15.7441 15.4657 24.4907 0]
      ifoc: [-0.0010 -2.3180e-04 0.0555 -0.3113 -0.3522 -0.3113 0.0555 -2.3180e-04]
     label: {'ITMback'  'ITMlensr'  'SR3'  'SR2'  'SRM'  'SR2r'  'SR3r'  'ITMlens'}

XARM =

    lambda: 1.0640e-06
         q: -1.8377e+03 + 4.3420e+02i
         N: 2
      dist: [3.9945e+03 3.9945e+03 0]
      ifoc: [8.9119e-04 0.0010]
     label: {'ETMX'  'ITMX'}

YARM =

    lambda: 1.0640e-06
         q: -1.8356e+03 + 4.3599e+02i
         N: 2
      dist: [3.9945e+03 3.9945e+03 0]
      ifoc: [8.9012e-04 0.0010]
     label: {'ETMY'  'ITMY'}

Here the relevant fields are:
q: input beam parameter
N : number of optics
dist : distance between the optics (d/n if in glass, i.e. NOT optical thickness d*n, since this is only for the modal calculation); one more than optics
ifoc : inverse focal length (either 1/f for lenses or 2/R for reflective optics)1 label: label of optics


The cavity overlap in the model is quite good:
Mode-matching of PRC to average arm: 99.9976 %
Mode-matching of PRC to X arm: 99.9988 %
Mode-matching of PRC to Y arm: 99.9959 %
Mode-matching of SRC to PRC: 99.8424 %
Mode-matching of SRC to X arm: 99.8136 %
Mode-matching of SRC to Y arm: 99.7878 %
Contrast defect between x and y arm, incl Schnupp asymmetry, but without reflectivity imbalance: 5.0033e-06


Note that without the 5cm SR2 move that was just completed the SRC looks significantly worse:
Mode-matching of SRC to PRC: 96.8874 %
Mode-matching of SRC to X arm: 96.7677 %
Mode-matching of SRC to Y arm: 96.666 %



The code is located at /ligo/home/controls/sballmer/20171207/beamCalc.m. It uses custom MATLAB libraries in /ligo/home/controls/sballmer/lib. The library includes a number of mode propagation plotting and overlapping tools.

Estimating the new contrast defect

Stefan, Thomas

In light of the new ITMX and ETMs being installed before O3, Stefan thought it would be a good idea to try to estimate the new contrast defect by calculating the fundamental mode of  each arm cavity before and after the swap using data from the core optics galaxy page and propagating the beams to a common point and calculating the contrast defect via this equation:

Two methods:

- Stefan used handwritten MATLAB code,which is located in ligo/home/controls/sballmer/20171207,  takes into account the arm cavity modes and the Schnupp asymmetry.

- I used Finesse with the aLIGO design and modifying the optics to the most in-situ numbers for ROCs (attached .kat parameter file and custom function to find eigenmodes).  This model includes the arm cavities and the Schnupp asymmetry, as well as the thermal lens which is approximated at f=34.5km and the michelson length.

When looking at the contrast defect on the HR surface of the arm cavities, both models are consistent, which makes sense because its the simplest calculation.  However, when propagating the beam to a different point such as the beamsplitter, things get more complicated because of the lenses caused by the AR surface of the ITMs and beamsplitter are estimates at best.  Although there is a slight difference in the q-parameters between the two models because of these effects, the way we calculated the contrast defect is the same.

The parameters we used were as follows:

Both simulations used the same ROC numbers, arm cavity length of 3994.5 meters and Schnupp asymmetry = 0.08m

Before Swap

	S/N	RoC
ITMX	03	-1939.90
ITMY	11	-1939.20
ETMX	08	2241.54
ETMY	12	2238.90



After Swap

	S/N	RoC
ITMX	07	-1940.30
ITMY	11	-1939.20
ETMX	13	2242.20
ETMY	16	2246.90



Results

Finesse

Location	Old Contrast Defect	New Contrast Defect
ITM HR Surface	5.93e-6	3.87e-6
BS HR Surface	5.68e-6	4.59e-6

Stefan's Code

Location	Old Contrast Defect	New Contrast Defect
ITM HR Surface	5.93e-6	3.87e-6
ITM + Schnupp	5.63e-6	5.00e-6

In the end, the interesting part which both models  agree on is that the contrast defect should be better with the new test masses.

It is important to note that we've only really considered the modal overlap, this has not incorporated the reflectivities of the ITMs which could make a difference in the end results if they are substantially imbalanced.
