Reports until 17:23, Wednesday 22 June 2016
H1 AOS (CDS)
david.barker@LIGO.ORG - posted 17:23, Wednesday 22 June 2016 (27926)
Tuesday maintenance summary, 21st June 2016

late entry for yesterday's Tuesday Maintenance

SUS PI

Carl, Dave, Terra, TJ:

new models for h1susetm[x,y]pi with associated DAQ restart.

Terra and TJ got the new Guardian GRD_SUS_PI node started.

New Vacuum Controls PID code for CP7

Patrick, Dave:

New code and epics database installed on h0vacey. New INI file installed with associated DAQ restart. New autoBurt.req file installed in target area.

New ASC model

Jennie, Jim, Dave

New h1asc model installed. After the build process we saw confusing archived INI files. We rebuilt, restarted and performed a DAQ restart.

New OAF model:

Jeff, Dave

A new h1oaf model was installed. Surprisingly the CPU processing time went up by 3uS from 53uS to 56uS. This is getting uncomfortably close to its 60uS limit. The changes made yesterday should not have done this. More investigation is needed. DAQ restart was not needed as this was a very unintrusive model change.

New dataviewer code

Jim:

Installed new dataviewer code with bug fix to trend the new double precision floating point data type.

new NDS2 client code

Jim:

version 12.2 nds2 client code installed on CDS.

mini-epics-freeze events

Sheila, Dave:

Sheila reported and alogged some epics freeze up events while viewing ASC and LSC data. I did a quick analysis using my IOP duotone channels which get to the DAQ via channel access and did not see any freeze-up in these channels for ASC and LSC. This appears to be a new phenomenon, investigation is continuing.

H1 CDS
david.barker@LIGO.ORG - posted 16:51, Wednesday 22 June 2016 (27925)
decoding a filtermodule's SWSTAT value; command line and graphical

runtime, graphical

For a running system a filter's SWSTAT value and its decoded switch bits can be viewed graphically by pressing the "GUARDIAN SET" button on the lower left of the filter medm. Of course these bits are also shown on the main medm, the FILTALH medm just shows just the switch settings more clearly.

command line, non graphical

For a command line decoding of the bits, Jamie has written the 'cdsutils sfm decode' function. This takes either one argument (the SWSTAT value) or two arguments (either SW(1,2) or SW(1,2)R). For a running system you can use either SWSTAT or the SW(1,2)(S,R) options. For past settings only SWSTAT is available from the DAQ. From conlog the SW(1,2)S values are also available, but they are equivalent to SWSTAT (filter engaged bits not available). Here is an example with SW(1,2)R supplied (so engaged bit data is shown).

cdsutils sfm decode 12292 1536

INPUT
FM5
FM5_ENGAGED
OUTPUT
DECIMATION

command line, graphical

Mike Thomas has written a python script called filterstate, which takes either SW(1,2)S or SW(1,2)R pairs as arguments and shows the switch settings graphically by creating a static png image which approximates to the standard filter module medm. Because only SWSTAT is available from the DAQ. I have written a script to convert SWSTAT to its equivalent SW(1,2)S pair called swstat2sw

For example, if the SWSTAT is 37904, the decode can be shown graphically with the command

filterstate $(swstat2sw 37904)

which produces the image shown below.

Images attached to this report
LHO General
thomas.shaffer@LIGO.ORG - posted 16:05, Wednesday 22 June 2016 (27905)
Ops Day Shift Summary

TITLE: 06/22 Day Shift: 15:00-23:00 UTC (08:00-16:00 PST), all times posted in UTC
STATE of H1: Commissioning
INCOMING OPERATOR: Corey
SHIFT SUMMARY: Commissioning work all day after 9, currently locked at 20W in INCREASE_POWER.
LOG:

H1 ISC
thomas.shaffer@LIGO.ORG - posted 16:01, Wednesday 22 June 2016 - last comment - 09:07, Thursday 23 June 2016(27923)
Added Bootstrapping to LASER_PWR Guardian

Since the calibration for the rotation stage doesnt seem to last too long, I added a bootstrapping method from rs_power_control.py (that I think Jamie made?)

At the end of the RS move, the bootstrap will move (requested_power^2) / (current power) further. This assumes that it is already close.

We tried it once going from 9.2W to a request of 20W and it went to 20.0W. Very nice.

Comments related to this report
matthew.heintze@LIGO.ORG - 09:07, Thursday 23 June 2016 (27936)

This was introduced by David Feldbaum at LLO and I am assuming that is where the code comes from (see LLO alog 13223)

H1 AOS (PEM, SEI)
conor.mow-lowry@LIGO.ORG - posted 15:52, Wednesday 22 June 2016 (27917)
BRS sensor correction Vs STS2 position
Conor, Jeff, Jim, Robert, Krishna

- Maximising coherence between the GND STS2 and the BRS is not necessarily the right move.
- Small gains at low frequencies might be made by moving the GND STS2 by some 10s of centimeters.
- Designing sensor-correction filters using offline data provides immediate quantitative performance metrics.

Robert's aLOG of ~1 month ago, 27170, showed
that coherence between seismometers (and the BRS) changes very rapidly with distance, presumably due to warping of the
floor or the wind acting like incoherent local sources. It was also apparent the magnitude of the tilt changed by a
factor of ~5 or more from the edge of the slab to a position far from the walls.

I wanted to see what the BRS-corrected seismometer performance is like as a function of position. Unfortunately the
BRS-corrected sensor isn't saved to science frames (H1:HPI-ETMY_STSINF_C_Y_IN1_DQ), and it really should be. On the
other hand it made me import all the appropriate filters into Matlab to perform offline sensor correction. This allows
me to evaluate whether we should move the Ground STS2 to a position that is more coherent with the BRS. Attachment 1,
'GND_spectra.png' shows that the ground motion spectrum is roughly equivalent in the three cases I looked at:
1) 06 May, STS2 huddle
2) 08 May, PEM-STS2 right next to BRS center
3) 13 May, PEM-STS2 at a position with low tilt, on the far side of the BSC, as far from the walls as possible.
These correspond to points 1, 3, and 6 from Robert's post.

1) Huddled STS2s, attachment 2, 'Huddle_BRS_correction.png'
Sensor correction works nearly identically on both devices, using the low-frequency cumulative RMS as a figure of merit.
Note that I only accumulate RMS below the microseism to better see sensor correction performance.

To get this level of sensor correction, I had to multiply the BRS output by 0.85 for the GND device, and 0.7 for the
PEM device (in addition to the 'match' filter of 0.85). This means that, even when huddled and coherent, there is ~18%
less tilt in the PEM device. This is the cause of the better low-f performance, where incoherent BRS noise dominates.

2) PEM next to BRS center, attchment 3, 'BRS_center_BRS_correction.png'
The coherence between the STS2 and the BRS at this position is slightly higher than at the GND position. Perhaps
this is visible near to 0.1Hz. However, to get good performance, I had to multiply the BRS out by 1.5. This factor is
solely responsible for the worse low-frequency performance.

3) PEM at low-tilt position, attachment 4, 'low_tilt_BRS_correction.png'
Due to its 5.5m distance from the BRS and GND-STS2, there is almost coherence below 0.1 Hz. The best RMS performance
comes, unsurprisingly, with no BRS sensor correction. The corrected seismometer wins by a factor ~2 down to 10mHz.

My conclusion from all this is that: Moving the GND-STS2 to increase coherence is not the correct thing to do.
Moving it ~40cm may surprisingly result in a 18% reduction of noise injection from the BRS with no real loss.
There may be additional gains to make in this fashion. Moving the BRS to a lower-tilt position, along with the
GND-STS2 may help, but ideally the BRS will be in a place with higher, but still coherent tilt.

Conclusion #2: while looking at this sensor correction, it became clear that significant gains can be made in the
BRS sensor correction performance both in global gain and in the high-pass BRS blending filter. I will try to find
a long, windy period for 'training' this filter.

Conlusion #3: placing STSs in low-tilt positions (like STS_ITMY in the beer garden) is already quite beneficial, at
the factor 2 or more level. The low-tilt position at ETMY seems to perform as well as the buried seismometer, and for
some reason much better during the 13 May stretch of data.

Images attached to this report
H1 ISC
stefan.ballmer@LIGO.ORG - posted 15:29, Wednesday 22 June 2016 - last comment - 15:50, Friday 24 June 2016(27922)
Recycling gain too low at 57W

Nergis, Peter, Stefan,


Currently, as we transition from 10W to 57W input power, our recycling gain drops from about 34 to 27. It seems like we need to tune the common TCS:



Attached are 3 plots:



Plot 1: DC signals:

PR_GAIN and normalized arm power (both blue)
AS_DC A and B (green and red)
POP_DC A and B (cyan and purple)
REFL_DC A and B (yellow and black)

Note the interesting behaviour of the REFL DC, all while AS_DC is linear in power.



Plot 2:

Arm and power recycling cavity powers, as well as test mass pitch control signals. The test masses have to compensate for radiation pressure, making the pitch control signal proportional to the arm cavity power.

Plot 3: RF signals:

Power and signal recycling cavity sideband buildups.

Images attached to this report
Comments related to this report
jenne.driggers@LIGO.ORG - 01:21, Thursday 23 June 2016 (27934)

[Jenne, Stefan, Peter]

We sent a lot of CO2 power to the ITMs today for a short period of time, once at 20W PSL power and once at 40W PSL power.  The idea was that if the recycling gain drop was due to central heating from the intracavity power, we should be able to mimic that by heating with the CO2 lasers and see a drop in recycling gain.  However, we don't see a drop in recycling gain, so it's not a heating / mode matching problem.  The drop in recycling gain really is due to misalignment effects, mostly SOFT yaw.



We set the Yarm TCS to 2.4W, and the Xarm TCS to 4.0W for the durations of these tests.  See attached that we didn't see any effect in any buildups or recycling gain.

Images attached to this comment
sheila.dwyer@LIGO.ORG - 15:50, Friday 24 June 2016 (27955)

Here are some plots that show that the X arm is getting misalinged in yaw durring the lock that Stefan was invesitagting power recycling gain loss for.  The first plot shows the transmitted green power, which is dropping for the X arm but not the Y arm.  We don't use any ASC control for the green light while in full ock, but by leaving it injected we can tell when the alignment of an indivdual arm is changing.  The second plot shows the Transmon QPDs for both pit and yaw, showing that X yaw has the largest change durring this lock.

Images attached to this comment
H1 ISC (ISC)
haocun.yu@LIGO.ORG - posted 15:26, Wednesday 22 June 2016 (27920)
40w HARD Loops Measurements

Jenne, Sheila, Haocun

We took measurements on the hard loops with 40w (actually 37w) laser power today.

The results are plotted with the modeling.

Images attached to this report
Non-image files attached to this report
H1 SEI (PEM, SEI)
david.mcmanus@LIGO.ORG - posted 15:19, Wednesday 22 June 2016 - last comment - 12:00, Thursday 28 July 2016(27919)
L4C Huddle Testing

David.M, Jenne.D

Yesterday I set up the sensors for the Newtonian noise L4C array in the beer garden. There are 31 sensors there in total (30 for the array and 1 spare), I arranged them in a huddle beneath the stairs near the STS-2. 20 of them are plugged into the two chassis located in the beer garden which correspond to the first 20 L4C channels. The other chassis is located external to the beer garden next to HAM2, I only connected two sensors to this rack because of a lack of long cables. The channels with these two sensors are L4C channels 26 and 30. I've attached a table which states which serial number L4C is connected to which channel for reference. Also attached are a photo of the current sensor huddle as well as an initial plot of the sensor spectrums calibrated to the STS-2 (thick black line).

The sensors themselves are each only touching the floor (despite what it looks like in the photo), although each wire touches many other wires and don't have any proper strain relief yet. The sensors currently being recorded are the ones more closely huddled together in the photo. The ones which are seperated slightly off to the left are the currently unrecorded L4Cs.

Images attached to this report
Comments related to this report
david.mcmanus@LIGO.ORG - 12:00, Thursday 28 July 2016 (28700)

A second huddle was performed by swapping out channels 11 to 18 with the 8 sensors that had not yet been tested. This swap occured on 6/28/16, the sensors listed on those channels for the original huddle were swapped out on that date and replaced with the new L4Cs. The table attached to this comment lists all L4C serial numbers along with the channel number they were connected to during the huddle (3rd column, the 5th column is the current channel for the array), and also the start and stop dates for when that L4C was connected in the huddle. If the L4C was never swapped out, both dates on this range are blue. The date 6/28/16 is in red to make it obvious that the L4C was swapped in or out on that date.

Non-image files attached to this comment
H1 SUS (ISC, SUS)
jenne.driggers@LIGO.ORG - posted 15:12, Wednesday 22 June 2016 (27918)
ETMY moving a lot

Why is the ETMY motion so different in character than all the other test masses?  All 4 test masses have angular control applied right now, but ETMY looks crazy.  I see it on the oplevs, as well as the L2 OSEMs, so I think it's real motion.

Images attached to this report
LHO VE
kyle.ryan@LIGO.ORG - posted 15:12, Wednesday 22 June 2016 (27921)
Manually over-filled CP3
1445 - 1500 hrs. local -> To and from Y-mid

Opened CP3 exhaust check-valve bypass valve, opened LLCV bypass valve 1/2 turn -> LN2 @ exhaust in 59 seconds -> Restored valves to as found.

Next manual over-fill to be Friday, June 24th.

H1 ISC
stefan.ballmer@LIGO.ORG - posted 13:36, Wednesday 22 June 2016 (27916)
SRC1 loops closed at 37W

The guardian is currently set up to go to 40W requested (actualkly 37W).. With the interferometer sitting at this power level for ~1h I picked a possible SRC input matrix: Both A36I and B36I have signal, but different offsets. The combination below brings us to a good sideband buildup:

for SRC1_P:
AS_A_RF36_I : -0.5
AS_B_RF36_I : +1.0

for SRC1_Y:
AS_A_RF36_I : -1.5
AS_B_RF36_I : +0.34

Attached are snapshots of the input matrices at 37W



Images attached to this report
H1 TCS
peter.fritschel@LIGO.ORG - posted 13:27, Wednesday 22 June 2016 - last comment - 16:43, Wednesday 22 June 2016(27915)
Arm cavity Higher Order Mode (HOM) spacing at 37 W input

The attached plot shows the arm cavity higher order mode spacing as calculated by Aidan's on-line thermal simulation (TCS_SIM). At 37 W input, the HOM spacing in each arm cavity increases by 60 Hz (X arm) and 75 Hz (Y arm) - relative to the no power-loading case. The ring heater configuration was constant during this time: both cavities had 1 W (total) RH power on the ETM, and no RH power on the ITM. The plot shows that the HOM spacing increases by 30-40 Hz in going from 18 W to 37 W input. If the 15.5 kHz PI modes are stable at 18 W, then we can increase the ETM RH powers to reduce the HOM spacing by 30-40 Hz, and they should then be stable at 37 W. This requires additional RH power of 0.5 W (total, top + bottom).

Couple things to note:

The X-arm simulation output shows a long time constant, but the Y-arm does not. The simulation does include a low pass filter for the surface change due to laser beam self-heating, to simulate this heating time constant. However, this low-pass filter was only engaged for ITMX. I have turned on the filter (surfTF, in FM1) now for all 4 test masses.

The arm cavity power calculation used in the simulation seems to be off. At 37 W input, it is using about 75 kW for both arms, when it should be closer to 150 kW. Something to look into.

Images attached to this report
Comments related to this report
terra.hardwick@LIGO.ORG - 16:43, Wednesday 22 June 2016 (27924)

Around 20:00 UTC we increased the ring heater power on both ETMs from 0.5 --> 0.75 top and bottom. We've had a few longer locks at 37 W since then and the previously problematic 15.5 kHz peaks have remained low with the RH power increase. Eventually we were able to turn off all active damping and still no sign of PI.

Power spectrum below shows the 15.5 kHz mode group as seen in the OMC DCPDs before RH increase kicking in and after RH increase. Note that in the before state, we were also actively damping with the ESDs. In the after state, we were not actively damping.

Images attached to this comment
H1 SEI
hugh.radkins@LIGO.ORG - posted 09:45, Wednesday 22 June 2016 (27909)
H1 HAM ISI CPS Noise Review--All look fine

Similar to the BSC look here.  Just looking at the higher frequency noise level indicating a problem.  All the HAMs look fine in this regard.  See the attached from diaggui template:

/ligo/svncommon/SeiSVN/seismic/HAM-ISI/H1/Common/CPS_Sensor_Spectra_HAM_ISI.xml

Images attached to this report
H1 SEI
hugh.radkins@LIGO.ORG - posted 08:50, Wednesday 22 June 2016 (27908)
Update of BSC CPS Noise

See logs 27648 27622 27549 27479 & 27475 for various looks & reports of the noise seen on BSC CPS channels.

In 27622, it is seen that ITMX Stage 1 has a very noisy V1 channel.  This morning's view has no such issue for any of the stage1 CPSs (this was also reported in 27648.)  The stage2 H3 channel however does now show a slight increase of noise relative to the others.   All other BSC CPSs look good.

Images attached to this report
H1 ISC
terra.hardwick@LIGO.ORG - posted 05:59, Wednesday 22 June 2016 - last comment - 10:07, Wednesday 22 June 2016(27904)
Damping new and old PI, 15521 Hz & 15541 Hz

We had three PI modes - 15522 of ITMX and 15541 of ETMX and 15542 or ETMY- ring up tonight and were only able to damp successfully ~40 W for a few hours; around 4am local time ITMX and ETMY began ringing up (despite fully driving both ESDs) and broke the lock.

At 4:42 UTC we originally lost lock from ITMX and ETMX modes ringing up, shown below:.

 In low power, I drove and damped each test mass to match it with it's peak. Here is a spectrum in low power with peaks labeled for this 15540 Hz mode group.

Tonight, 15521 Hz on ITMX was first damped easily but 15541 on ETMX is tricky since we don't have LV ESD on ETMX until further in the locking process. As Sheila mentioned, we tried switching to LV ESD ETMY so I could turn the LV ESD on for ETMX, but had some troubles and ultimately opted to not damp ETMX tonight but rather try remaining < 50 W. By 2 am we were successfully damping ITMX and (preventatively) ETMY ~40 W. A bit before 4am local, 15521 (ITMX), 15542 (ETMY) began ringing up. I'm having trouble grabbing data during these stretches to track the line amplitudes, so here's a spectrum showing the peak amplitude progression (in UTC times). It looks like ITMX led the ring up. Its not clear to me if ETMX went unstable.

We'll need to play with phases and iWave today to see if that helps strengthen damping.

Damping directions (for now) for 15522 of ITMX, 15541 of ETMX, 15542 of ETMY:

1. From orange PI button on sitemap, choose ITMX / ETMX / ETMY --> OMC OVERVIEW --> MODE2 / MODE 1 / MODE 4

2. BP and DAMP filters are populated correctly. DAMP filter gain around saturation with sign - / ? / +

Images attached to this report
Comments related to this report
rich.abbott@LIGO.ORG - 10:07, Wednesday 22 June 2016 (27913)ISC, SUS
Terra, it is at least theoretically possible to change the ETM LV Driver such that the HV path be active AND an AC coupled LV path (PI) active simultaneously.  It would require some hacking and head scratching, but I don't see that it's impossible at this time.

A high voltage relay selects between the LV mode and the HV mode for each quadrant.  As you know, the HV mode doesn't have much PI drive capability, whereas the LV drive does.  The trick would be to bypass the relay contacts between the LV and HV sides with a high voltage capacitor of 1 to 2nF.  There is a 10k resistor in series with the HV side, so we would tie in on the optic side of the 10k with the bypass capacitor.  Using 1.6nF would put the RC highpass corner at 10kHz, which would slightly reduce the drive amplitude at 10k, so a compromise of corner frequency and PI drive amplitude can be struck.

Let me know, after exhausting other possibilities, whether or not this is worth pursuing.
H1 ISC (GRD)
sheila.dwyer@LIGO.ORG - posted 00:01, Wednesday 22 June 2016 - last comment - 12:02, Wednesday 22 June 2016(27901)
50+ Watts, stable for 10 minutes

Corey, Nergis, Stefan, Sheila, Terra

We were locked above 50 Watts for ~10 minutes.  Our high bandwidth HARD loops along and the ISS 3rd loop are keeping us stable enough to power up, but we still have some things to work out.

Our first high power lock broke as we continued to increase the power beyond 50 W and a PI rang up.

Durring our second attempt Terra damped one PI, (separate alog coming) but we lost lock by increasing the power, ringing up a different PI, and ringing up the bounce modes.

We attempted to switch to ETMY at 20W so Terra could try damping a PI on ETMY, but found that we saturated the low noise driver with the high ASC noise we have right now.  We engaged the Jenne Low passes in CHARD, which stopped the saturations at 20W, but we started to saturate again and lost lock as we tried to increase the power on ETMY.   We will probably need to figure out how to power up on the low noise driver so that we have the option of damping PI on all test masses.

In our last attempt we let the guardian power up to 40 Watts, the power up took about 10 minutes, the only steps we did manually were engaging the ISS 3rd loop and turning off the bounce mode damping.  We lost lock at 40 Watts around 9:18 UTC because of a problem with the ISS 3rd loop.

Images attached to this report
Non-image files attached to this report
Comments related to this report
keita.kawabe@LIGO.ORG - 12:02, Wednesday 22 June 2016 (27914)

1. During power up from 2W to 50W, power-normalized arm transmission decreases by about a factor of 0.7 (attached).

That's a factor of 0.7 decrease of the optical gain of the 3rd loop. That's probably not enough to make something funny to the 3rd loop but it's something you need to know about.

And anyway, where's the power gone? MC transmission looks good, it should be IFO.

2. It might be possible to engage the 2nd and the 3rd loop at the same time before powering up, and changing the 2nd loop offset slider while powering up.

The reason why we need to adjust the offset is because the 2nd loop is DC coupled. Before engaging the 2nd loop (or 3rd loop) we run the offset adjustment servo, which is very slow due to double 0.1Hz pole in the offset path plus one 0.1Hz pole in the 2nd loop servo path itself. It's somewhat accelerated by digitally undoing a part of the delay, but it's impossible to undo three 0.1Hz poles without saturating the board badly.

However, once the 2nd loop is engaged, we only have to fight against two 0.1Hz poles to change the offset, so the task is somewhat easier (and quicker).

3. For engaging 2nd loop and 3rd loop at the same time, we need to change 3rd loop filter.

In principle all we need to do is to disable FM9 (boardComp) and set the gain correctly.

Images attached to this comment
H1 SUS (DetChar)
betsy.weaver@LIGO.ORG - posted 15:15, Tuesday 21 June 2016 - last comment - 23:54, Saturday 02 July 2016(27893)
TUESDAY Maintenance SUS OSEM noise hunt - SAT AMP Power Cycles

Richard, Filiberto, Ed, Betsy

Following on from Andy's probing alog 27841 regarding funny looking OSEM spectra, today we looked into a few fishy signals.  Based on spectra he took from before and after the early June power outage which show signal changes, he and Jenne identified the following set of problematic OSEM signals.  I've annotated the list with status as to what we found or fixed today:



ITMY L2 LR - Fixed after power cycling the Satallite Amp box (see alog below)

ITMY R0 RT - Signal looks funny before power outage, old problem, TBC...

MC1 M3 UL - Signal looks funny before power outage, old problem, TBC...

PRM M2 UR - Fixed after power cycling the Satallite Amp box (see alog below)

PR2 M1 T2 - TBC...

PR2 M3 UL - Giant nominal YAW Bias which has been on this SUS for over a year - very little signal on OSEM - mechanical fix when vent

PR2 M3 LL - Giant nominal YAW Bias which has been on this SUS for over a year - very little signal on OSEM - mechanical fix when vent

SR2 M1 LF - Funny comb feature, TBC...

SR2 M1 T1 - Funny comb feature, TBC...

SR2 M1 T3 - Funny comb feature, TBC...

ETMX L2 LL - 50Hz turn up noise, TBC... Turn up is due to LOCK ACQ PUSHING, turn up not present during nominal SUS damping, no LOCK ACQ, see below plot

ETMX L2 LR - 50Hz turn up noise, TBC... Turn up is due to LOCK ACQ PUSHING, turn up not present during nominal SUS damping, no LOCK ACQ, see below plot

ETMX L2 UR - 50Hz turn up noise, TBC... Turn up is due to LOCK ACQ PUSHING, turn up not present during nominal SUS damping, no LOCK ACQ, see below plot



ETMY L2 UR - 50Hz turn up noise, TBC... Turn up is due to LOCK ACQ PUSHING, turn up not present during nominal SUS damping, no LOCK ACQ, see below plot

IM3 M1 LL - TBC...



We plan to pursue ITMy R0 and SR2 this week at next opportunity.

Comments related to this report
betsy.weaver@LIGO.ORG - 15:43, Tuesday 21 June 2016 (27894)

Before doing the sat amp power cycle, we first tried a coil driver power cycle on a few of our funny OSEM sets.  This did not appear to clear the errant noise in any of the 4 cases.  We then embarked on the sat amp power cycle which cured the 2 shown in the above list.  Tomorrow we hope to revisit ITMY R0 RT and SR2 M1 which we have left off troubleshooting today with only coil driver OFF spectra.  (Betsy, tomorrow you should use the attached spectra as a jump off point.)

TBC...  Note the wildly different looking symptoms both of which were seen by Lundgren in 20675 AUG 2015.

Images attached to this comment
betsy.weaver@LIGO.ORG - 15:45, Tuesday 21 June 2016 (27896)

Attached is the ITMY L2 OSEM signal spectra shown from before and after today's fix.  The PRM M2 OSEM before and after-fix spectra are very similar to this.

Images attached to this comment
betsy.weaver@LIGO.ORG - 09:58, Wednesday 22 June 2016 (27911)

ETMX High freq turn up during LOCK ACQ, not a stand alone OSEM signal feature.

Images attached to this comment
betsy.weaver@LIGO.ORG - 10:03, Wednesday 22 June 2016 (27912)

ITMy R0 RT investigation - this morning Richard and Fil performed another round of tests on the ITMy R0 RT (shared cable and electronics with R0 LF, M0 RT, M0 LF).  After power cycling the SAT box, other SAT box cable reseating, and reseating of the main cable to the chamber, the noise on this channel still exists.

SR2 M1 bouncy noise on 3 of 4 TOP investigation - Richard and Fil powert cycled the Sat AMp box for this set of 4 OSEMs, but the noise is still there.

TBC...

andrew.lundgren@LIGO.ORG - 23:54, Saturday 02 July 2016 (28136)DetChar, ISC, SUS
As requested by Betsy, I've made another set of spectra of the OSEMs. The green line is July 1 10:18 UTC. The reference time (black) is a time near the Boxing Day event (Dec 26 2015 4:30 UTC). This is because the OSEMINF channels are only stored in the commissioning frames, and those aren't stored for very long. But we did store them around events in O1.

If we need to do these checks often, then we will need to 1) Store the OSEMINF channels in raw frames. 2) Occasionally save commissioning frames for some time in known-good states 3) Write some code to dump spectra to a file occasionally.
Non-image files attached to this comment
H1 CAL (ISC, SUS)
jeffrey.kissel@LIGO.ORG - posted 14:27, Tuesday 21 June 2016 - last comment - 09:46, Wednesday 22 June 2016(27890)
ETM ESD Bias Signs Flipped; Beginning Regime of Regular Flipping
J. Kissel

After measuring charge today, I've flipped the BIAS sign on both ETMX and ETMY.

In addition, I've changed the compensation scheme downstream of the BIAS flip such that signs are flipped in each quadrant's ESDOUTF bank GAIN instead of being convoluted in the the DRIVEALIGN matrix elements. This separates the functionality, compensates any angular control as well as longitudinal (though we don't send any angular control to the test mass stage at the moment), and minimizes the possibility for losing the fine-tuned DRIVEALIGN gains.

Finally, I've modified the ISC guardian in such a way that it monitors the BIAS, and takes care of flipping all of the additional settings necessary to compensate for the bias change in the DOWN state. It had formerly had the DRIVEALIGN gain values hard coded, which was already bad news. Now the ESDOUTF gains (which have not been tuned / balanced as of yet) are flipped between -1 and +1; much easier to maintain. Also, I've added changing the CAL-CS settings to match as well, so the change in calibration will be taken care of as well.

I would post the latest results from today's change measurements, but I've been stuck trying to get 1 second of EPICS data from NDS2 for about 4 hours now.

Details
------------------
Before Flipping (to preserve my sanity, and minimize minus signs):
- Moved DRIVEALIGN negative signs into the ESDOUTF bank:
          ETMX              ETMY
      OLD       NEW       OLD     NEW
L2L   -1          +1       -30     30
L2P   -0.021  +0.021         0      0
L2Y   -0.007  +0.007         0      0
and the ESDOUTF GAINs had all been positive unity, were flipped to negative unity so as to not yet actually flip the compensating sign.

Then, I changed the ETMX bias sign:
- Changed H1:SUS-ETMX_L3_LOCK_INBIAS from +9.5 to -9.5 [V_DAC]
- (unlike before) The ISC_LOCK guardian (now) takes care of checking the sign of H1:SUS-ETMX_L3_LOCK_INBIAS, and adjusting the sign of
   - H1:SUS-ETMX_L3_ESDOUTF_[UL,LL,UR,LR]_GAIN from -1.000 to +1.000  (fixes the ESD stage longitudinal loop gain to match the bias sign change)
   - H1:SUS-ETMX_L3_ESDOUTF_LIN_FORCE_COEFF from +124518.4 to -124518.4 (fixes the linearization force coefficient to match the new bias sign)
   accordingly.
- (like before) Accepted the new values in *all* SDF snap files,
   /opt/rtcds/userapps/release/sus/h1/burtfiles/
   - h1susetmx_down.snap
   - h1susetmx_observe.snap
   - h1susetmx_safe.snap
  by loading in each table and accepting the values I've changed, followed by a commit to the userapps repo.
- (like before) There's no need to make any further changes in the CAL-CS epics settings, because ETMX is not used in any capacity for calibration.

Followed by the ETMY bias sign:
- Changed H1:SUS-ETMY_L3_LOCK_INBIAS from -9.5 to +9.5 [V_DAC]
- (unlike before) The ISC_LOCK guardian (now) takes care of checking the sign of H1:SUS-ETMX_L3_LOCK_INBIAS, and adjusting the sign of
   - H1:SUS-ETMY_L3_ESDOUTF_[UL,LL,UR,LR]_GAIN from -1.000 to +1.000  (fixes the ESD stage longitudinal loop gain to match the bias sign change)
   - H1:SUS-ETMY_L3_ESDOUTF_LIN_FORCE_COEFF from -124518.4 to +124518.4 (fixes the linearization force coefficient to match the new bias sign)
   accordingly.
- (like before) Accepted the new values in *all* SDF snap files,
   /opt/rtcds/userapps/release/sus/h1/burtfiles/
   - h1susetmy_down.snap
   - h1susetmy_observe.snap
   - h1susetmy_safe.snap
  by loading in each table and accepting the values I've changed, followed by a commit to the userapps repo.
 (This also involved *creating* a copy of the down.snap in the userapps repo, and changing the file in the
  target/h1susetmy/h1susetmyepics/burt/ directory to a soft link, as was already the case for the OBSERVE.snap and safe.snap)

[Making sure Calibration is unaffected]
- (like before) We must make sure that the CAL-CS replica of the ETMY actuation matches the SUS ETMY digital signal chain. However, because the CAL-CS model had not been restarted, and its SDF system had been kept up-to-date it did not lose the appropriate settings, so the settings for
   - H1:CAL-CS_DARM_FE_ETMY_L3_DRIVEALIGN_L2L_GAIN to +30.0
   - H1:CAL-CS_DARM_FE_ETMY_L3_ESDOUTF_UL_GAIN to +1
   - H1:CAL-CS_DARM_ANALOG_ETMY_L3_GAIN stays +1.0
- (unlike before) Again, to be consistent, I've changed the sign of the linearization force coefficient,
   - H1:CAL-CS_DARM_FE_ETMY_L3_ESDOUTF_LIN_FORCE_COEFF from +124518.4 to -124518.4
- (unlike before) Accepted the new values in *all* SDF snap files,
   /opt/rtcds/userapps/release/sus/h1/burtfiles/
   - h1susetmx_observe.snap
   - h1susetmx_safe.snap
  by loading in each table and accepting the values I've changed, followed by a commit to the userapps repo.
 (Since there is no change between the "down" and "observation" state, a "down" .snap doesn't and need not exist.)
Images attached to this report
Comments related to this report
sheila.dwyer@LIGO.ORG - 01:52, Wednesday 22 June 2016 (27903)

Something is wrong with ALS DIFF, is seems to saturate constantly.  Is something wrong after the bias flip?

jeffrey.kissel@LIGO.ORG - 09:46, Wednesday 22 June 2016 (27910)
Looks like the Linearization Force Coefficient some how got flipped back to +124518.4. We fixed the sign there, and made sure it was coded correctly in the ISC_LOCK guardian and moved on. To 50+ W no less!
Displaying reports 56241-56260 of 83402.Go to page Start 2809 2810 2811 2812 2813 2814 2815 2816 2817 End
