Jennie W, Camilla

We set up this measurement by mis-aligning ITMX, ITMY, BS, PRM and SRM during the maintenance period (after the PSL and IM suspensions came back up).

NB. PSL was at 2W but ISS was off.

Then we adjusted IM3 till we were centred in pitch and yaw on IM4 TRANS.

Then we searched each direction of IM1 and 2 that gave us clipping on IM4 TRAns - IE. THE nsum DROPPEED.

Then we went back to a point near clipping on IM 2 and mpved IM1 in that DOF to try and bring back the NSUM since we managed to do this for all DOFs (up and down in pitch and yaw)we assume no translation oft he beam improves NSUM so we are probably not clipping through OFI.

First image is starting sliders.

Second is sliders after we  aligned IM3.

This is ndscope trends throughout our tests. By far the largest improvement to IM4 Trans was moving IM3 and nothing we did with IM1 or 2 really improved this.

This morning I tweaked up the PSL PMC alignment remotely using the picomotor-controlled mirrors with the ISS off. I was only able to get about 60mW of power increase out of the PMC, but I decreased reflected power by about 200mW, so perhaps there's some mode-matching that could be optimized in the future.

After that, I recalibrated the rotation stage using the following process:

• Took IMC offline and paused LASER_PWR guardian
• Ran the script /opt/rtcds/userapps/release/psl/h1/scripts/RotationStage/MoveRotationStage.py to create PSL_rotStageCalib_2Apr2024.txt (attached)
• Changed PSLvals in CalibRotStage.m for correct file name then ran to create calibration curve (attached) and get new fit values (in table)
• Input new fit values into calibration and accepted new values in SDF (screenshot attached)
• Searched for HOME on rotation stage
• Resumed LASER_PWR guardian to go back to 2W input power

J. Oberling, R. Crouch, T. Guidry

Since the last update we have tried a couple of things.

First, we attempted to align the FARO to the BSC2 chamber directly.  We placed the FARO in the biergarten and shot the chamber-side door flanges.  We used the SMR to sweep along the outside of the +X side of the +Y door flange, and the +Y side of the +X door flange.  The shots were done as circles, which we could then place a point at circle center to represent the center of the door flange.  The hope was we could then project lines to represent the X and Y axes, and use that to align to our origin using a Plane/Axis/Center Point alignment routine.  I won't go into much detail, as it didn't work.  We used this alignment to look at PSI-6 in the biergarten, and it was off by over 1cm; we then looked at LV-35 and that one was off by even more.  I don't remember exact values as we didn't save screenshots since the devaiations were so large.  Let's say that if these deviations were true, I'm not sure how we would have a functioning, aligned, and alignable IFO.  So, that experiment didn't work, moving on.

Today we decided to try using height marks 901, 902, and 903 to set our Z axis alignment.  We looked at marks 901 and 902 with an autolevel and compared them to our BSC2 door flange scribe average we had used the water tube level to measure (alog 75974) and the listed local Z coordinate from T1100187.  Results:

• 901:
  • T1100187: -54.7 mm
  • Water level: -55.2 mm
  • Difference: -0.5 mm
• 902:
  • T1100187: -62.7 mm
  • Water level: -62.9 mm
  • Difference: -0.2 mm

Not bad, and definitely not the almost +4mm the FARO was measuring for these marks w.r.t. BTVE-1.  If we use our differential height survey from alog 75771 we can also calculate the local Z axis coordinate for mark 903, which comes out to -79.8 mm (versus the listed coordinate of -79.9 mm from T1100187), and again not the almost +4mm reported by the FARO when measured w.r.t. BTVE-1.  It's looking more and more like there was some error in the Z axis position of BTVE-1; whether that error was in setting the monument itself or in setting BSC2 w.r.t. to BTVE-1 we cannot say.  The fact of the matter is that when compared to BSC2 as it sits right now based on our water level survey, the height marks we've looked at are pretty close to their listed coordinates and BTVE-1 is definitely not.  We also happened to do the same differential height survey with BTVE-1 (also in alog 75771), so we can calculate a local Z coordinate for BTVE-1 based on our height mark 903 (which we have now tied to BSC2 Z=0).  Doing so gives a local Z axis coordinate for BTVE-1 of -1060.3 mm (Z₉₀₃ - deltaZ_BTVE-1/903 = -79.8 - 980.5); this becomes -1060.9 mm once we convert to our global coordinate frame (which is decidedly not the -1057.2 mm all of the old documentation lists it as).

Now that we have local Z coordinates for 901, 902, 903, and BTVE-1 that have all been tied to BSC2 Z=0, we used these to set a new alignment.  First, we need global Z coordiantes for our 3 height marks.  We got these by using a autolevel to set a magnetic nest inline with the height mark to be measured.  The FARO was put into an intial alignment using BTVE-1, PSI-1, PSI-2, and PSI-6 (X and Y are generally pretty good, Z is off but we don't care yet), and we then placed the SMR on the nest we placed inline with 903.  From this we got an X/Y coordinate for the nest that we could use to calculate our global Z.  Once this was done we added 903 into the alignment routine, and removed PSI-1, PSI-2, and PSI-6 for the Z axis fit.  we then moved the FARO to a position where we could see 901 and 902 and shot them in the same way we did 903.  Ultimately, we ended up with an alignment using BTVE-1, PSI-1, PSI-2, and PSI-6 for X and Y and 901, 902. and 903 for Z.  The coordinates used for the height marks were (format is [X,Y,Z]):

• 901: [1075.8, 12366.1, -55.7] mm
• 902: [1078.9, 24938.8, -63.3] mm
• 903: [1082.6, 37455.6, -80.0] mm

Tyler has a screenshot of the results of the alignment that he'll post as a comment to this alog.  One thing to note here: We were not using the new BTVE-1 Z as part of the Z axis alignment, only marks 901, 902, and 903.  It's somewhat comforting to see the Z axis coordinate of BTVE-1 as calculated by the alignment routine as close as it is to what we think the nominal shoud be based on our water level survey of BSC2.  The PSI monuments are all out, especially PSI-2.  I'm not sure how concerning this is, as we don't trust the Z coordinates of the PSI monuments anyway.

One caveat here, all of the height marks we used are almost in a line down the Y axis, with very little deviation in the X axis coordinate (a deltaX of less than 7mm across ~25m of the Y axis).  I'm not entirely confident we're picking up the global tilt of our X axis with this configuration.  We want to take this alignment and test and refine it; first thing we can do is get some more height marks spread along the X axis to hopefully catch the global X axis tilt.  More to come!

The BRSX remote mass adjust pico motor was finally connected to the EX pico controller this morning. This was done with the pigtail D2400020 that Fil made, to allow the BRS to use channel 5 on the controller. Channel 5 is then sent to a DB9 that goes into the box, and connects to a DB9 soldered to the pins on a feedthru on BRSX vacuum vessel.

I tested that we are able to run the motor from the MEDM, and made an adjustment to the mass on the BRSX to try to get us better centered. I can now recenter the BRS from my office, nice.

The pico controller screen is accessed through LSC->Picmotors->End X (X PICO A) screen. To recenter push "Enabled", push the  wait for the err codes to clear, set the step size and speed. "Sprint" is fine for the speed, for the BRS at least. The motor is, I think, 10k steps per revolution, when UW was here, we used 1250 steps per move. Today, I went +2250 steps, saw that was the wrong direction, then -5000 steps from and then a final +1000 steps to disengage the mass adjuster drive yoke. The net move was -1750 steps. This is recorded in epics as H1:SYS-MOTION_X_PICO_A_CURRENT_X_POSITION, but that seems to depend on the channels selected on the chassis.

 The buttons on the pico motor screen are kind of confusing " < " makes positive steps, and " > " is negative. This moved the BRSX driftmon channel about -20k counts, and it just barely on the bottom edge of it's readout range. I've turned the voltage on the heater down to bring it back to center, but that will take a day or two to settle out, so I've taken the BRS out of loop for now.

Summary (highlights) of findings during the DQ Shift

-Engineering run with ongoing commissioning
-Numerous lock-losses due to earthquakes/seismic activity
-BNS range averages between 145 and 150 Mpc. Sometimes there are fluctuations to 130 Mpc.
-Glitchgrams show a reoccuring glitch around 40 Hz that occurs a few times a day.
-The h(t) spectrogram showed sporatatic increases of amplitude relative to the median in low-frequency range. Anomalies can be associated with drops in BNS range.
-Fscans are unavailable at this time.
-A few pyCBC triggers with new SNR > 10 (short) occured 2 out of 7 days.
-PEM, ASC and LSC type channels showed often as round winners in Hveto associated with low-frequency noise around 40 Hz and 50 Hz respectively.
-New channels of interest include IMC and HPI. Channel activity can be linked to sustained winds. Also could be round winners because of shorter observation runs.



DQ Shift Report:

https://wiki.ligo.org/DetChar/DataQuality/DQShiftLHO20240318

Attachment 1 - Unsqueezed (left) vs. squeezed (right) DARMs in ER16, with respect to O4a. Like Gabriele's plots, the ratios on the bottom show a given trace / O4a reference, so ratio > 1 means more noise now than O4a.

• (left) Last night's no-sqz time 76872 looks quite similar to O4a around 100 Hz, so maybe any excess non-quantum noises around 100 Hz are improving?

• (right) Squeezing does not look super optimal right now - definitely would be interesting to do more optimization.. It both looks highly frequency-dependent, and SQZ possibly even lossier now than earlier in ER16, though this is very difficult to say. Recently we've been optimizing SQZ around 350 Hz for range, so it's hard to evaluate high-freq SQZ, since it is misrotated due to the strong frequency-dependence. But even recent ASQZ efficiency could use another look. Maybe we could check OPO temperature, try re-running alignment scripts, etc. General SQZ efficiency is worth some investigations, alongside optimizing PSAMS or SRCL.

Colors: Rainbow colors are ordered past to present: e.g. Red = O4a, ... Purple = now.

Attachment 2 - SQZ dBs after subtracting non-quantum noise, with various recent PSAMS settings. Upper subplot: Anti-SQZ, Lower subplot: SQZ. Lines are a moving average of the data. Some caveats for the subtraction: here I am using the same H1 unsqueezed quantum noise model for all subtractions; this may not be the most accurate, but I think it should be fairly close.

Reference alogs wth times that I used to grab GDS_STRAIN_CLEAN:

• O4a references - 74935 and Gabriele's times from 76825
• 76434 - PSAMS 120/120, March 17
• 76540 - PSAMS 150/90, March 20
        --> corresponding SQZ data set saw ~10-15% higher frequency-dependent losses at 100 Hz vs. kHz unlike earlier Mar16, possibly due to PSAMS settings following 76507
• 76777 - PSAMS 100/100, March 29
• 76798 - PSAMS 125/125, March 29  low-freq glitch in this short SQZ time, difficult to compare. Expect it is similar to 120/120 data?
• 76825 - PSAMS 100/100, March 30  - Gabriele showing total DARM at 100 Hz similar to O4a
• 76872 - PSAMS 100/100, April 2 - opportunistic NO SQZ from last night.

This could be a bad readback, or real, we are not sure.  The signal should be 23dB, but the readback is showing 16.8dB on NDSCOPE and has been trending down for a while, it is throwing an error flag in beckhoff.  This signal is located in ISC-R1 slot U16 on the left side.  The LO signal is 9MHz and is fed through a delay line chassis, there are also baluns, cabling, etc...  We were not able to determine the source of the readback error before noon, so this will have to wait until a maintenance window.

M. Pirello, F. Mera, D. Sigg

This morning I flipped the sign (after talking to the Operator) of the ETMX ESD lock bias voltage from -450V to +450V for 3hrs to reduce the charge build up in the optic.

After 3hrs I reversed the sign and set it to nominal.

ndscope trends are attached below.

Per WP11795 I looked at the EX Accelerometer Power Conditioner based on what Robert said about one of the channels not functioning.  Visually, there is no power on channel 8, the power good light is off.  We moved the signal to channel 9 and will go back to fix channel 8 when time permits.  This channel was working when the chassis was installed.

Lights off, paging system unplugged, WAP stayed off. Some unused extension cords unplugged, genie lift charging block unplugged. Turned off SQZ laptop and monitor.

All else looked good, followed T1500386

WP 11799.

Patrick T., Ryan S.

The PSL Beckhoff PLC has been updated to match the changes made at LLO to add a watchdog channel. This is the code from 'TwinCAT Projekt_LIGO_240124.zip' in https://dcc.ligo.org/E2100235. The now running version is in git at https://git.ligo.org/cds/ifo/beckhoff/lho-psl and commit 9b6ad86cb26660b136242b334bd4831a683f1c5b. It appears there was also a change to fix a bug where toggling the noise eater tripped the NPRO. Ryan verified that this now appears to be fixed. I also removed the ${IFO}.PSL.LASER.MAIN.SHUTTER alias of the bEnable_Shutter2 variable, which according to LLO is not being used. The channel was not being exported to EPICS.

There were two minor issues. The first was that the version of a couple of the terminals found from a scan of the EtherCAT bus did not match what was in the IO configuration, and this appeared to be the cause of an INIT error for a couple of terminals (presumably those) when the system was put into run mode. This was fixed by changing the IO configured versions to match the scanned versions. The other was that I forgot to comment out the inversion of the signal from laser PD1, which was not realized until we started everything and were wondering why the power was reading as negative for that PD. I fixed that in a new commit and restarted the code again.

Tue Apr 02 10:06:37 2024 INFO: Fill completed in 6min 34secs

Jordan confirmed a good fill curbside

Picket Fence was updated.  The only major change is that one channel "HLID" was dropped for another, "HWUT".

We have an upgrade slated today for the PSL Beckhoff computer; I captured a screenshot of the settings table in case it gets overwritten and am posting it here for posterity.

Camilla, Vicky

Screenshot of how we found the SQZ_FC and SQZ_OPO this AM. Two separate issues.

Only to-do might be fixing the SQZ_FC issue in FIND_IR. I hope the SQZ_OPO_LR issue is solved, but we will watch out for it.

More description of the issues from this morning/last night and how to fix it:

• SQZ_FC -  same stuck in FIND_IR issue as yesterday 76862. See the execution time over-run circled in today's guardian screenshot.

  • To fix: brought SQZ_FC to "DOWN". That was it, SQZ_MANAGER took over the rest.

  • To-do: Unsure why we have gotten multiple timeouts in the past 2 days, try to resolve this.
    • Maybe in SQZ_FC, on Line 112, we need to wrap the cdu.getdata() function call in TJ's timeout checker function.
    • In the meantime, I have added a log statement to Line 111 just before cdu.getata() is called, and reloaded SQZ_FC. So if FIND_IR gets stuck again, we can confirm whether it is really this function call that times out the guardian.

• SQZ_OPO_LR - did not scan to high enough PZT voltage to find co-resonance. Hopefully we have now increased the scan range enough to fix this for O4b. Steps taken today:

  1. From it being STALLED and MANAGED, I took SQZ_OPO_LR to AUTO. This worked to un-stall it, and let it continue locking. If the scan is fixed, this should be enough to solve the problem.
      --> Not sure why OPO guardian was "STALLED" when it jumped to "IDLE" state, but I think this is related to the guardian "jump" to IDLE. I'm not sure if we even want to fix this -- leaving the SQZ_OPO_LR guardian in STALLED was probably the correct move, otherwise it would have spent hours scanning the PZT without finding co-resonance. Better to fix issues with not finding co-resonance, maybe not much to do here.

  2. OPO couldn't lock on co-resonance b/c that was at 104V, but PZT1 was only scanning up until 100V -- I changed the scan offset.

     • OPO did not find co-resonance within its scan range, then it timed out, jumped into IDLE, and the guardian STALLED. See sqz locking screenshot -- increasing the scan range let it find co-resonance at 104V, and then SQZ_MANAGER easily went back up to FDS.

     • I increased H1:SQZ-OPO_PZT_1_OFFSET from 0V to 15V, and saved this 15V offset in SDF. We cannot increase H1:SQZ-OPO_PZT_1_SCAN_STOP above 100V in slowcontrols, so we have to increase the scan offset to get the PZT there.

       • Note, back when OPO_PZT2 was at 0V (before 76688), I think the OPO would often find co-resonance between 100-110 V during O4a.

     • Based on a previous opo co-resonance issue, 76642 seemed to want to the scan starting around ~50V. Today's issue shows we want to scan beyond 105V, probably up to 110V or even 115V (the max). Based on OPO cavity scans (e.g. screenshot from LHO:75285), I think OPO PZT1 is not super effective (in terms of um/V scanning) below 50V or so.

     • Let's try scanning from 55V - 115V to guarentee we find co-resonance. This is how it's currently set. This corresponds to the first screenshot, where H1:SQZ-OPO_PZT_1_OFFSET = 15V (saved in SDF), H1:SQZ-OPO_PZT_1_SCAN_START = 40, H1:SQZ-OPO_PZT_1_SCAN_START = 100V.

Paused TCS_ITM_CO2_PWR guardians so that when the IFO unlocks the CO2s will stay on so we can take absorption measurements of the ITMs using HWS (need ITMs and SR2 to stay aligned for 1 hour after lockloss).

J. Kissel
ECR E1700387
IIET 9392
WP 11743

Here, this week we tackle the last of the suspension types that need suspension watchdog upgrades after having finished the End Station, Corner BSC, and HAM Triple suspensions this past month (LHO:76269, LHO:76545, and LHO:76712, respectively).

WP 11797
While doing so, I'm also going to address the OMC ASC routing bugs found in the h1susifoout top-level model and its OMCS_MASTER library part (which used to live in h1susomc.mdl), and fix those too.

As such, I'm doing a linear combination of the following changes:
    (1) In library part, removed sending watchdog out to top level
    (2) In library part, removed ODC parts from DAMP and LOCK banks
    (3) In library part, removed never-usered software shutter system
    (4) In library part, upgraded watchdog trigger generator to actual functional RMS
    (5) At top level, removed USER DACKILL
    (6) At top level, removed wires to ground (i.e. things never used) at top-level for WD, SHUTTER, and ODC outputs and SHUTTER input
    (7) At top level, cleaned up receiving of ISC ASC signals (see discussion in LHO:76842)

Below is the list of models, their respective library parts, and the optics in that model that this impacts, followed by a call out of which of the above changes happened
h1susim       HSSS_MASTER    IM1, IM2, IM3, IM4      (1), (2), (4), (5), (6)
h1sushtts     HSSS_FF_MASTER RM1, RM2                (1), (2), (3), (4), (6)
h1susifoout   OMCS_MASTER    OMC                     (1), (2), (4), (5), (6), (7)
              OFIS_MASTER    OFI                     (1), (2), (4), (6)
              HSSS_MASTER    OM1, OM2, OM3           (1), (2), (4), (5), (6)
h1sussqzout   HSSS_MASTER    ZM4, ZM5, ZM6           (1), (2), (4), (5), (6)
h1sussqzin    HDDS_MASTER    ZM1, ZM3                (1), (4)
              OPOS_MASTER    OPO                     (1), (2), (4), (6)
              HSSS_MASTER    ZM2                     (1), (2), (4), (5), (6)

I've test-compiled all of the above listed models, so they're ready for re-compile, install, and restart of the front-end process tomorrow morning.
All model changes have been committed to the userapps repo, either under
    /opt/rtcds/userapps/release/sus/h1/models/
    /opt/rtcds/userapps/release/sus/common/models/
where the above mentioned models live.

Screenshots describing the changes will be posted in the comments.

J. Kissel, [Corroborated by J. Wright and J. Driggers]
WP 11797

While upgrading the OMCS_MASTER.mdl library part for the OMC Suspension (which now lives in the h1susifoout.mdl top-level model), I found two distressing things:
    (1) The OMC ASC signals that are sent from the h1omc.mdl model -- running at 2kHz -- are not anti-imaged at all before being sent to the OMC SUS DAC -- running at 16 kHz. So, we're sending unnecessary imaging noise to the SUS DAC.
    (2) The OMC ASC L, P, amd Y signals are being sent through a filter bank that does NOT past through the DRIVEALIN matrix, rendering 2019's attempt at diagonalization (LHO:47488) unused.

These bugs have been long standing.
I see it now as I touch the h1susifoout.mdl and the OMCS_MASTER library part for watchdog upgrades, but I'd previously identified the issue when
 - I was upgrading the front-end models for O4 (i.e. when the OMC SUS transitioned from the h1susomc.mdl to the h1susifoout.mdl) in 2021 (LHO:59652), and
 - When we were identifying which SUS models used the broken "TrueRMS" bloick -- there's a preceding note in the simulink model that suggests this has been around since 2015 or earlier.

We can fix this tomorrow, with *only* a change to the h1susifoout.mdl and OMCS_MASTER.mdl models, and we're already doing that anyways for the SUS watchdog upgrade.


Attached are several series of screenshots showing:
    (1) The signal path from the h1omc.mdl model where the OMC ASC control signals begin, to where they land in the OMC SUS driving in the EULER basis (again WITHOUT going through the DRIVEALIGN MATRIX)
    (2) MEDM Screens showing that in practice we only drive L, P, and Y (as one should for an ASC signal) and we don't use T, V, or R drive and likely never will.
    (3) The existing filters that will need to be copied over, and the DRIVEALIGN gain values that will likely need to be re-addressed -- since effectively we've NOT been using them.

Note -- I checked on how this is done at LLO, and they *do* drive through the LOCK banks and DRIVALIGN banks (BUT they don't have any anti-imaging filters in pace either, even though their ISCINF FM1 banks are ON... whoops)...
So, when we change the OMCS_MASTER library part, this won't affect them.
