As commissioning started again, there was a commissioning caused lock loss. We are relocking now and almost back up. When we return to low noise commissioning will continue.

Sheila, Naoki, Camilla

Started testing a phase dither on the SQZ LO that dithers the SQZ angle, so that we can eventually demod the change on the SQZ BLRMS and use for monitoring and adjusting the SQZ level.

Yesterday

Sheila had already added all elements needed to the h1sqz model under H1:SQZ-PHASE and Naoki made a new medm screen (sitemap > sqz > sqz overview  > sqz omc blrms > phase dither). GEO600 uses something similar to this and it's in 'Quantum noise locking' K.McKenzie Paper.

In the SQZ racks we plugged in the DAC output for the DITHER_OUT output into IN2 of the SQZ LO servo (chassis in right rack, slot 16). We had to unplug the "ISC_SQ_232" cable from IN2 of the LO board. If we want to the lock the LO using the homodyme again, we'll need to revert this.

Today during commissioning time we injected a 7.2Hz signal via H1:SQZ-PHASE_DITHER_OSC .

Copying whats used in ADS dither locks, we added added a bandpass around 7.2Hz to PHASE_DITHER_DEMOD_SIG to see the sqz angle dither using SQZ BRLMs #4, added low pass at 2Hz to PHASE_DITHER_DEMOD_{I,Q} as the 7Hz x 7Hz gives us a 14Hz and a 0Hz signal, we only want the 0Hz.

We made the #4 SQZ BLRMS use a wider band pass, was 700 to 800Hz, now 700 to 1750Hz. The signal got smoother, so we could think about expanding all the SQZ BLRMS.

Can already see the change demoded signal having a zero crossing a maximum and minimum squeezing as expected, see attached, where Sheila stepped the SQZ angle via the 'ezcastep' command. We still need to tune the demod phase to minimize Q and understand what amplitude we should use. We can also think about if we can achieve similar SQZ angle monitoring using the ADF signal.

To turn this back on: need to turn on IN2 on SQZ LO servo and put an amplitude in H1:SQZ-PHASE_DITHER_OSC_CLKGAIN. Other settings saved in sdf.

I've released a new version of the ndscope trend plot generator. The new system is more automated, making it easier for anyone to add trends to the system. Details are in the User Guide, which is a wiki page linked at to bottom of the web page.

Ndscope Trends

Wed Nov 15 10:04:59 2023 INFO: Fill completed in 4min 56secs

Gerardo confirmed a good fill curbside.

Taking some time to do some opportunistic commissioning while LLO is down.

A contractor is on site to blow out our sprinklers. This work requires a large compressor to move air through the underground water lines near the OSB. Since we are observing and this specific noise source has not been vetted, we are marking the times here.

Rough start time: 1610 UTC

End time: Unfortunately we don't have a good end time. We would guess that this work would take roughly 30 minutes or less.

TITLE: 11/15 Day Shift: 16:00-00:00 UTC (08:00-16:00 PST), all times posted in UTC
STATE of H1: Observing at 151Mpc
OUTGOING OPERATOR: Corey
CURRENT ENVIRONMENT:
    SEI_ENV state: CALM
    Wind: 4mph Gusts, 3mph 5min avg
    Primary useism: 0.02 μm/s
    Secondary useism: 0.28 μm/s
QUICK SUMMARY: Locked for 6 hours, calm environment. Only alarm is the PT524B EX vacuum gauge that the vac team has been working on. Plans today consist of some commissioning time in the afternoon.

TITLE: 11/15 Eve Shift: 00:00-08:00 UTC (16:00-00:00 PST), all times posted in UTC
STATE of H1: Observing at 159Mpc
INCOMING OPERATOR: Corey
SHIFT SUMMARY: Pretty quiet night, I ran a calibration suite, and the range has been steadily just under 160 Mpc. Lock time of 9:35 at the end of the shift.

03:02 dropped observing to run a calibration measurement alog74212

03:32 Back to NLN, the DARM fom timed out during the state transition and I had to restart it

03:33 back into Observing

I've seen the MC3 camera on NUC26 flash blue a few times.

I ran the analysis for the OPLEV charge measurements on ETMY that Rahul took this morning. The charge on ETMY is fairly stable, some small increases and decreases on the quadrants since the last measurement.

• H1 Observing at 158 Mpc
• We've been locked for 5:33
• I dropped us out of Observing from 03:03 to 03:33 to run a calibration measurement

Following the wiki I ran a calibration measurement while LLO was still relocking.

Starting with the BB

NLN calibration screenshot

03:02 NLN to NLN_CAL_MEAS

03:04 Broadband measurement started:

• /ligo/groups/cal/H1/measurements/PCALY2DARM_BB/PCALY2DARM_BB_20231115T030313Z.xml

03:09 Simulines:

PST start: 2023-11-14 19:09:20.280160 PST
UTC start: 2023-11-15 03:09:20.280160 UTC
GPS start: 1384052978.280160

2023-11-15 03:31:25,595 | INFO | File written out to: /ligo/groups/cal/H1/measurements/DARMOLG_SS/DARMOLG_SS_20231115T030922Z.hdf5
2023-11-15 03:31:25,644 | INFO | File written out to: /ligo/groups/cal/H1/measurements/PCALY2DARM_SS/PCALY2DARM_SS_20231115T030922Z.hdf5
2023-11-15 03:31:25,657 | INFO | File written out to: /ligo/groups/cal/H1/measurements/SUSETMX_L1_SS/SUSETMX_L1_SS_20231115T030922Z.hdf5
2023-11-15 03:31:25,671 | INFO | File written out to: /ligo/groups/cal/H1/measurements/SUSETMX_L2_SS/SUSETMX_L2_SS_20231115T030922Z.hdf5
2023-11-15 03:31:25,683 | INFO | File written out to: /ligo/groups/cal/H1/measurements/SUSETMX_L3_SS/SUSETMX_L3_SS_20231115T030922Z.hdf5

PST end: 2023-11-14 19:31:25.778909 PST
UTC end: 2023-11-15 03:31:25.778909 UTC
GPS end: 1384054303.778909

Closes FAMIS 26066, last checked in alog73538

I had to change the env to get the plots to show as RyanS mentions in alog73432

TITLE: 11/15 Day Shift: 16:00-00:00 UTC (08:00-16:00 PST), all times posted in UTC
STATE of H1: Observing at 153Mpc
INCOMING OPERATOR: Ryan C
SHIFT SUMMARY: Maintenance day recovery was fairly straight forward, with one lock loss on the way to low noise. We've been locked for almost 2 hours now.
LOG:

• 1612 Lock loss to start maintenance
• 2130 Lost lock at Laser_Noise_Suppression.
• 2252 Observing. ISS 2nd loop had no issues this time (alog74204)

TITLE: 11/14 Eve Shift: 00:00-08:00 UTC (16:00-00:00 PST), all times posted in UTC
STATE of H1: Observing at 151Mpc
OUTGOING OPERATOR: TJ
CURRENT ENVIRONMENT:
    SEI_ENV state: CALM
    Wind: 7mph Gusts, 5mph 5min avg
    Primary useism: 0.03 μm/s
    Secondary useism: 0.50 μm/s
QUICK SUMMARY:

• All systems look good, microseism still a little high, range looks to be rising
• In observing since 22:52 UTC

Sheila, Ryan S, TJ

Today we went down to EX and looked at the UGFs for the PLL and the PDH, and then the I/Q ratio. To do this we connected the SR785 to the correct common mode chassis (Sheila knew which was which as labels were lacking), and then turned on the test output on the medm screen. We then looked at the I/Q ratio and adjusted the demod phase (H1:ALS-X_REFL_A_PHASE_PHASEDEG) to increase this ratio. Started at around 12.5dB @120deg and ended up at 115deg as the ratio become nonsensical with Q approaching 0 (picture). This value is now saved in SDF.

This isn't a large change, so we don't expect to see much of a difference but it will be good to compare this to EY when we get a chance to get down there.

WP11524 Upgrade sw-msr-h1aux

Jonathan, Tony, Patrick Dave:

The MSR switch sw-msr-h1aux was upgraded to new hardware by Jonathan and Tony (see Jonathan's alog for details).

Several restarts were needed following the upgrade to restore servers which are connected to this switch. Several cameras attached to h1digivideo[0,1,2] became unresponsive. We first tried to restore these by restarting individual processes on the digivideo machines but eventually decided to reboot the original server h1digivideo[0,1,2]. Note that nothing needed restarting on the new h1digivideo3 server.

The tp mon IOC froze around this time (08:52 PST) and was restarted on cdsioc0.

WP11521 New h1sqz model change

Daniel, Dave:

Daniel made a h1sqz model change, adding 7 filter modules. This required a DAQ restart

DAQ Restart:

Dave:

A fairly unremarkable retstart except both GDS needed a second restart to sync their channel lists.

Cell Phone Alert System Back Using Twilio

Dave:

On Saturday our Twilio toll free number was verified by the Campaign Registry and we were able to use it to send SMS text messages again. I decided to wait until H1 lost lock, and 79 hours later this happened at the start of today's maintenance. I reverted the hybrid code I had been running (Twilio for phone calls, cellphone providers for SMS) back to the Twilio-does-it-all code.

Took MICH FF measurements following instructions in lsc/h1/scripts/feedforward/README.md but running MICHFF_excitation_ETMYpum.xml. Data saved in lsc/h1/scripts/feedforward/ as .txt files. Last tuned MICH in 73420.

I saved a new filter in FM6 as 27-10-23-b (red trace) but it made the MICH coupling worse between 20 and 80Hz so we left the original (pink trace). We could try to re-fit the data to load in Wednesday's commissioning period.

Following up on the observtion that the SRCL FF is increasing the DARM low frequency (2-3 Hz) motion (73561) and that this motion might be the origin of non-stationary noise (73546), I designed a new high pass filter for SRCLFF and retuned the FF.

The new high pass gives us about 4 times less reinjection between 2 and 4 Hz, at the price of a phase rotation of 20 degrees at 10 Hz. Therefore the old SRCL FF was not performing well anymore. I did a noise inection and refit the FF filter. Fitting this filter is tricky and I don't think I got an optimal solution. But it looks like the new highpass with the new FF performs fine, is at least as effective as the old highpass and the old FF, by looking at the coherence between DARM and SRCL.

DARM RMS is improved a little between 3 and 4 Hz, so maybe we'll see some improvement in the non-stationary noise. We need to figure out what else is making DARM noise at 3.4 Hz. There is also an enormous line at 1.23 Hz that is the cause of most of DARM RMS. I think the bicoherence shows that the 1.23 Hz line is a source of noise modulation too.
