H1 has 30 sender RFM channels on each arm, of which only 26 have corresponding receiver(s). So 4 are being sent and no model is using the data.

L1 has 29 senders on the X-ARM (of which there are 26 receivers), and 30 senders on the Y-ARM (of which there are 26 receivers).

So the two sites are very close in number of sending channels.

Analysis details: The base number of potential senders was derived from the main IPC file, looking for RFM0 and RFM1 ipc types. This resulted in 30 for H1-X and H1-Y, and 42 for L1-X and L1-Y. Because the ipc file is only appended to during compilation, if it has not been cleanly regenerated recently it may overcount the number of sending channels.

For each channel, I searched the models' RCG generated IPC_STATUS.adl medm file for the channel name (e.g. H1LSC_IPC_STATUS.adl). Assuming that no two ipc channels share the same name, if I found the channel name in the adl file this means it is a running sender with a receiver. For the remaining possible senders without receivers (H1-X=4, H1-Y=4, L1-X=16, L1-Y=16) I looked for the channels in the top level simulink source files (e.g. /opt/rtcds/userapps/release/*/l1/models/l1*.mdl). This showed that all four channels on H1-X and H1-Y do have sending models, and for L1-X 3 of the 16 had sending models, and for L1-Y 4 of the 16 had sending models.

If we can possibly remove some of the RFM channels which are not being received, additional RFM channels can be added to the loop with no risk.

For H1 the sending channels with no receivers are:

• H1:OAF-PEME[X,Y]_RFM
• H1:ASC-[X,Y]_TR_A_SUM_RFM
• H1:ALS-[X,Y]_ARM_RFM
• H1:ALS-[X,Y]_REFL_B_LF_RFM

The cooling system failure at the H-2 electronics building (FRS 4271) was due to a defective flex joint in the line set from a outdoor unit compressor to the building. The flex joint has been replaced and the line set and compressor are being drawn down. There will be a small vacuum pump running near the outdoor units throughout the night. If there are no more leaks, the unit will be recharged with gas and back running tomorrow. The vacuum pump will run unattended, however, if there are any issues with the running of the pump, please do not hesitate to call me.
The commissioners have been apprised of this also.

1545 - 1605 hrs. local -> To and from Y-mid

Next CP3 over fill to be Friday, Jan. 29th before 4:00 pm

State of H1: realigned and relocking and currently between DRMI and Engage ASC

Shift Details:

• Richard and Filiberto worked at EY this morning, to recover the ETMY ESD drive
• They used the ETMX ESD drive temporarily to compare the logic
• Bubba started working on shimming the West Bay crane - more time needed
• Richard and Filiberto worked on cabling for TCS - more time needed, scheduled for tomorrow morning
• No outstanding issues on H1 at this time.

The picomotors for the TCS are as follows:

• PICO_F = CO2X
• PICO_G = CO2Y
• PICO_H = HWS

The following screens have been modified to fix links to the TCS picomotors so that they are correct:

• TCS_HWS.adl
• TCS_CO2P.adl
• TCS_MASTER.adl (for passing arguments to the previous two screens)

All files have been committed to the SVN

Justin's web page contains a lot of very useful links, I have linked it at the bottom of the CDS home page.

I changed the label for button PICOMOTOR_H on the isc/commom/medm/ISC_CUST_PICOMOTOR_OVERVIEW.adl screen from "TCS HAM5" to "HWS table". I also changed the "name" argument associated with this button to "HWStable" so that this appears as the title of the picomotor screen that pops up when this button is pressed.

These changes were committed to the SVN.

Looking at the problems from last night I began looking at the ESD this AM.  Noticing that the main read back for driver was flickering on and off I by-passed the LV driver and looked only at the HV driver.  It was obvious the DC bias was not present.  Hoping it was not the Driver itself looked at the incoming DAC channels and all functioned except the DC bias channel.  Tracked it down to the output of the IO chassis.  Filiberto replaced the 18bit DAC, ribbon cable and interface card.  This cleared up the issue.  While working on this noticed the ESD can get into some odd states when the on/off switch is pressed.  I think we still have some binary issues that latch the unit up.  Was able to clear the problem by going to the BIO screen and changing states.

We've been working on a script to try improve the function of the rotation stage which controls the waveplate setting the power output to the CP.  The script is now working, but we had problems yesterday with stability of the rotation stage control. The Y rotation stage stopped responding to requests.  It's not clear what the cause of this problem is, but restarting the EtherCAT chassis for the rotation stages appears to fix the problem at least for a period of time.  After a first restart the X-arm rotation stage which is currently in use, started to exhibit problems.  The stage would correctly find home, but any angle request caused it to move randomly.

I re-calibrated the Y-arm rotation stage.  The X-arm one does not appear to be correctly calibrated which may be a BURT restore issue.  However this only affects calibration of power to angle, and should not affect operation for angle requests.

At this point I've completed the control script but don't plan on implementing it while the rotation stage is not working in a stable manor since the script asks the stage to move multiple times and may increase the tendency for it to fail.

Script is located at userapps/trunk/tcs/common/scripts/TCS_CO2P_SETPOWER.py

TJ, Laura

We've been working on tracking the RF45 glitches to veto them out of the astrophysical searches. We were initially tracking the control point of the RF45 MHz amplitude stabilization loop, H1:LSC-MOD_RF45_AM_CTRL_OUT_DQ, which seemed to be correlated with the severe glitching in DARM. However, as O1 progressed we noticed that the monitors we had built for this channel were missing some periods of severe glitching in DARM that we recognized as RF45 glitches. During these periods, the 45 MHz amplitude stabilization loop control point was completely quiet, but glitching was evident in MICH alignment degrees of freedom and DARM.

Since then, we've found that the most consistent witness to the RF45 glitches is a vertex alignment control signal, H1:ASC-AS_B_RF36_I_YAW_OUT_DQ. This signal is correlated with the glitches in DARM even when the 45 MHz amplitude control signal shows no discernable features. We've never seen any activity in the 9 MHz amplitude control signals during these glitchy periods. It doesn't seem like the amplitude stabilization of the 45 MHz sideband is the root cause of the noise in DARM, perhaps it's more of a witness to a broader issue in the RF electronics that commonly impacts generation of the 36 MHz signal.

19:42 UTC Started Conlog test code on conlog-test-master and connected it to the same 97,469 channels as the production code on h1conlog1-master.

We added and aligned the fast photodetectors (PDA50B) to the HWS table, per T1500579. The outputs from these photodetectors go into a whitening board (D1500430). The input channels in the ADC are adc0_22 and adc0_23 in the TCS CO2 model.

Alignment:

We used an IR card with mounted in a C-Ring and the Green Beam from the ALS to align to the center of the aperture on the photodiodes. See the before and after alignment photos:

Also attached is a photo of the whitening board.

Calibration:

The input channels in the real-time code are: H1:TCS-IFO_POLZ_S_HWS and H1:TCS-IFO_POLZ_P_HWS.

The filter banks in these channels:

1. Undo the whitening board (2x poles at 0.5Hz and 2x zeros at 10.9Hz)
2. Convert from counts to volts
3. Convert from volts to amps (+50dB transimpedance setting of PDA50B)
4. Convert from amps to Watts (divides by response = 0.56 A/W at 1064nm)

Also, the following DC offsets are added at the input based on measurements of the background value when the photodiodes were not illuminated:

• S_HWS_OFFSET = -28.76 counts
• P_HWS_OFFSET = 20.92 counts

From here, the outputs go into a 2x4 matrix for combination to produce S and P estimates for the power incident on the BS_AR surface. A rough estimate for these values are as follows:

• S_BSAR_INC = (1/R_BSAR_S) * (1/T_DCBS) * S_HWS= 1/0.027 * 1/300E-6 = 1.235E5 * S_HWS
• P_BSAR_INC = (1/R_BSAR_P) * (1/T_DCBS) *P_HWS = 1/34E-6 * 1/300E-6 = 9.8E7 * P_HWS

Based on the complex reflectivites of the BS for S and P, the ratio of S to P at the AS PORT increases by a factor of 39 from the BS_AR surface. We use the following parameters to calculate the polarization angle (in radians) at the AS PORT.

• S_ASPORT = 38.8*S_BSAR_INC = 4.79E6 * S_HWS
• P_ASPORT = P_BSAR_INC
• AS_THETA = ATAN( SQRT( S_ASPORT/P_ASPORT ) ) ~ SQRT( S_ASPORT/P_ASPORT )

We made some changes to the TCS front end models yesterday morning:

- tcs/common/models/TCS_MASTER.mdl

Added two relative intensity noise channels for the IN-LOOP and OUT-LOOP photodiodes. They are constructed from the ISS_AC divided by ISS_DC (if ISS_DC <= 0, the denominator of this division defaults to 1).

New channels are: H1:TCS-ITMX_CO2_RIN_INLOOP, H1:TCS-ITMX_CO2_RIN_OUTLOOP and are saved to frames at 1024.

- tcs/common/models/TCS_POLZ.mdl

This is a new library block that takes the input from the IFO polarizaation sensors and creates channels that are S and P measurements at the HWS table, incident on the BS AR surface and at the AS PORT. There is also a channel that is an estimate of the polarization angle at the AS PORT. These new channels are all saved to commissioning frames at 1024

- tcs/h1/models/h1tcscs.mdl

Added adc0 channels 22 and 23 to the adc input. Injected these into the polarization block.

All these files were uploaded to the SVN.

State of H1: down more than 24 hours, ESD drive EY is restored to previous state (low voltage only)

Summary:

• Richard and Filiberto have been back and forth to EY since 7AM PT
• ESD drive at EY is now restored, however...
• ESD drive at EY only works in low voltage configuration, which is a bug...
• Richard and Filiberto are looking into why high voltage is not working
• ETMY optic, TMSY, BSC10 HEPI, and BSC10 ISI are restored, so...
• I am starting an alignment

[JimW, Jenne, EvanH, Kiwamu, Sheila, Gabriele]

The new version of DTT seems only capable of getting a single channel of data at a time.

We have tried several different kinds of channels, and DTT will only give you the first channel in the list.  No good.

Jim, Evan

Does this behavior of the ETM ESD DAC outputs make sense? Here a large offset has been applied to the UL coil output filter. However, the screen suggests that it's being applied to the UR DAC channels.

This behavior is seen on both ETM ESD DACs, but not the ITM ESD DACs.

New lab dust monitors

Jeff B, Jim, Dave [WP5697]

As part of the install of the new OSB lab dust monitors:

generated new autoBurt.req file. Generated new DAQ EDCU INI file. Recanned conlog against autoBurt.req file.

New GDS version

Jim [WP 5696]:

completed this morning.

Clearing partially loaded filter modules

Was able to do full loads on susbs, susitmx, susitmy, susprm, sussrm. Still have partial loads on lsc, omc, suspr2 and sussr2 which are waiting for the system experts to clear.

DAQ reconfigure

DAQ EDCU was reconfigured for the missing h1tw0 and new DUST channels. Was applied during today's two DAQ restarts.

DAQ Restarts

In both DAQ restarts the dataconcentrator, tw1 and both framewriters started with no issues. In the first restart the broadcaster started by both NDS daqd process were no longer controlled by monit. A simple monit restart of the daqd processes cleared the error. On the second restart the broadcaster started, stopped and later restarted. Again both NDS processes did not start, and when they were restarted they failed. The error was that high dcuid nodes for the Beckhoff SDF system has been mistakenly added to the testpoint.par file, and only the NDS machines objected to this. The file was repaired and monit was able to restart the NDS daqd processes.

TCS model changes

Aidan and Dave [WP5688]:

Installed new h1tcscs model onto h1oaf0. DAQ was restarted.

New Beckhoff SDF code release

Jonathan [WP5695]:

Jonathan tested the new code on EY Beckhoff. He found an issue with enumerated binaries and backed this version out.

RACCESS monitoring/control of h1hwinj1

Jonathan, Jim, Dave:

Jonathan added the hardware injection machine h1hwinj1 to his RACCESS control system. MEDMs were updated accordingly.

H1OAF change to drive audio in control room

Richard, Evan, Dave [WP5704]:

h1oaf and h1pemcs models were changed to permit oaf to drive the 8th DAC channel of PEM's 18-bit DAC card. This analog signal is then routed from the CER to the control room using the audio channel in the digital video fiber link between the rooms.

New operator table install in the control room

Richard, Carlos, Jim, Dave:

The new powered, adjustable-height operator table was installed in the control room at the operator station. The access control PC, gate cam and alarm machines were shuffled to the left and a new workstation was installed on the new table.

HPI and ISI safe.snap work

Hugh, Dave:

Hugh worked on the safe.snap files for HPI and ISI. I was able to offer some help by creating a new script to convert sub-systems to safe SDF mode and converted all HPI and ISI to safe. Later I converted them back to OBSERVE mode.

New ECAT EPICS channels for corner station

Daniel, Dave:

Daniel made Beckhoff changes in the corner station. I updated the ECAT DAQ INI files and the target autoBurt.req files.

Server patching and rebooting

Carlos, Dave:

Carlos applied security patches and rebooted cdsssh, cdslogin and cdsadminctrl. We restarted the vacuum alarms system on cdslogin.

tl;dr: Alignment of IMs and RMs should be checked, then re-run an initial alignment.

Xarm green alignment

Ed was struggling with the Xarm green alignment.  We set the guardian to locked no slow, no wfs.  I then turned on the loops one at a time.  Usually the camera centering loops are the problem, but they were the easy ones this time.  Eventually it was DOF2 that was causing trouble, so I had DOFs 1 and 3 closed and touched TMS by hand to get the error signals for DOF2 closer to zero.  I was able to close all the loops, and let the alignment run like normal after that.

Xarm IR alignment

Not really sure what the problem is here, but it's getting late and I'm getting frustrated, so I'm going to see if I can move on with just hand aligning the input.

I suspect that the IMs need some more attention, so if Cheryl (or someone else following Cheryl's procedures) could check on those again in the morning, that would be great.

Also, I'm not sure if the RMs got any attention today, but the DC centering servos are struggling.  I've increased the limits on DC servos 1 and 2, both pitch and yaw (they used to all be 555, now they're all 2000).  I also increased H1:SUS-RM2_M1_LOCK_Y_LIMIT from 1000 to 2000.

Allowing the INP ASC loops to come on is consistently causing the arm power to decay from 0.85ish to lockloss. I didn't touch the ITM or ETM, but I'm not getting any more power by adjusting PR2 or IM4.

MICH Dark not locking.  Discovered that BS's M2 EUL2OSEM matrix wasn't loaded, so no signal being sent out.  Hit load, MICH locked, moved on.

Bounce needed hand damping (guardian will prompt you in DARM_WFS state), roll will probably need it too.  This isn't surprising, since it happens whenever the ISI for a quad optic trips.  Recall that you can find the final gains (and the signs) for all of these in the ISC_LOCK guardian.  I like to start with something small-ish, and increase the gain as the mode damps away.  No filters need to be changed, just the gains.  My starting values are in the table below, and I usually go up by factors of 2 or 3 at a time.

I lost lock while damping the bounce mode (in DARM_WFS state), and the DRMI alignment is coming back much worse than the first few DRMI locks I had.

I don't actually have a lot of faith in my input beam alignment, so I probably wouldn't be happy with any ASC loop measurements I take tonight even if I got the IFO locked.  Since we have an 8am meeting, I'm going to call it a night, and ask the morning operator to check my alignment and fix anything that sleepy-Jenne messed up.

Evan, Kiwamu,

As some of us have already noticed, there is a broadband noise with a 1/f^{0.5} shape in frequency from 60 to 200 Hz. This noise is unidentified.

Do not believe any statements in this report until futher analaysis. Something is fishy with the claibration of the cross-spectrum.

We are planing to check how stable this noise level is over the course of the entire O1.

The below shows an example spectrum of DARM.

Blue curves are twenty spectra of DARM (aka C01 frame, converted into displacement), each of which is made by the Pwelch with Hanning, detrended, 50% overwrap for a 12 minutes time series. The data starts at a GPS time of 1134604817. Green curves are the square-root of twenty cross-power-spectra of DCPD A and B which are reconstructed from the sum and null streams of the DCPDs. The DARM suppression effect was removed from the sum signal. The cross-spectra are then calibrated to the displacement using the latest O1 DARM model of the calibration group. No time varying correction (i.e. kappas) is applied. Red line is a 1/f^{0.5} line to show how steep the slope of the green curves is. I also attach the fig file.
